LIY(St)CY-TP

SHARE

Product Certificates

You can click to download our certificates.

Areas of Use

These double screened cables are used as signal transmission cables in industrial applications. These can be easily used with their flexible construction in narrow applications like electronic control systems of computer or audio systems or the communication sector, electronic circuits, measurement devices, machine design, office equipment, etc. These used for indoor applications. Screening protects the cable from the outer electrical effects.

Cable Construction

  • Conductor Stranded Annealed Copper (IEC/EN 60228, Class 5, 0.34 mm²: Class 2)
  • Insulation PVC (EN 50290-2-21)
  • Core Colors DIN 47100
  • Lay-up Cores are twisted as pairs and pairs are stranded in layers
  • 1. Screen Al-PET Foil
  • 2. Screen Tinned Copper Wire Braid (55% Coverage)
  • Outer Sheath PVC (EN 50290-2-22), RAL 7001 - Grey
  • Reference Standards VDE 0812, TS 13755

Technical Properties

  • Operating Voltage 0.14 mm²..0.25 mm² 250 V; 0.34 mm²..1.50 mm² 300 V / 500 V
  • Test Voltage 0.14 mm²..25 mm² 1200 V; 0.34 mm²..10 mm² 1500 V; 1.50 mm²….. 2500 V
  • Loop Resistance 0.14 mm²-≤276 Ω/km; 0.22 mm²-≤170 Ω/km; 0.25 mm²-≤155.6 Ω/km; 0.34 mm²-≤112 Ω/km; 0.50 mm²-≤78 Ω/km; 0.75 mm²-≤52 Ω/km; 1.00 mm²-≤39 Ω/km; 1.50 mm²-≤26.6 Ω/km
  • Insulation Resistance >200 M.Ωxkm
  • Capacitance (@800Hz) Core - Core: 0.14 mm²-≤80 nF/km; 0.22 mm²..0.34 mm²-≤100 nF/km; 0.50 mm²..0.75 mm²-≤110 nF/km; 1.00 mm²..1.50 mm²-≤120nF/km; 2.50 mm²- ≤140 nF/km Core-Screen: 0.14 mm²-≤120 nF/km; 0.22 mm²..0.34 mm²-≤150 nF/km; 0.50 mm²..0.75 mm²-≤170 nF/km; 1.00 mm²..1.50 mm²-≤180nF/km; 2.50 mm²- ≤240 nF/km
  • Indutance (approx.) 0.65 mH/km
  • Temperature Range Fixed: -30 °C ........+70 °C, Flexible: -5 °C ........+70 °C
  • Flame Retardancy IEC/EN 60332-1
  • Min. Bending Radius Fixed: 8 x Cable Diameter, Flexible: 15 x Cable Diameter

Cross Section

  • Configuration / Cross-Section (mm/mm²) Cable Diameter (mm) (± 5%) Copper Weight (kg / km) ~ Cable Weight (kg / km)
  • 2x2x0.22 5.5 16 40
  • 3x2x0.22 6.0 21 50
  • 4x2x0.22 6.4 25 60
  • 5x2x0.22 7.1 31 73
  • 6x2x0.22 7.8 36 86
  • 8x2x0.22 8.5 45 106
  • 10x2x0.22 10.1 56 136
  • 12x2x0.22 10.5 65 156
  • 2x2x0.25 5.7 17 42
  • 3x2x0.25 6.2 22 54
  • 4x2x0.25 6.8 28 67
  • 5x2x0.25 7.5 34 80
  • 6x2x0.25 8.2 40 95
  • 8x2x0.25 8.9 50 117
  • 10x2x0.25 10.6 62 150
  • 12x2x0.25 10.9 72 168
  • 2x2x0.34 6.1 21 50
  • 3x2x0.34 6.5 28 62
  • 4x2x0.34 7.1 36 77
  • 5x2x0.34 7.9 44 94
  • 6x2x0.34 8.6 51 110
  • 8x2x0.34 9.4 66 138
  • 10x2x0.34 11.3 81 179
  • 12x2x0.34 11.6 95 202
  • 2x2x0.5 7.4 27 70
  • 3x2x0.5 7.9 37 86
  • 4x2x0.5 8.7 47 108
  • 5x2x0.5 9.7 57 133
  • 6x2x0.5 10.6 67 157
  • 8x2x0.5 11.6 86 196
  • 10x2x0.5 13.8 106 252
  • 12x2x0.5 14.3 124 288
  • 2x2x0.75 8.4 37 88
  • 3x2x0.75 9.0 51 114
  • 4x2x0.75 9.9 66 142
  • 5x2x0.75 10.9 80 172
  • 6x2x0.75 12.0 95 206
  • 8x2x0.75 13.2 123 262
  • 10x2x0.75 15.6 152 330
  • 12x2x0.75 16.2 179 379
  • 2x2x1 8.9 47 104
  • 3x2x1 9.4 65 132
  • 4x2x1 10.5 84 169
  • 5x2x1 11.6 103 205
  • 6x2x1 12.8 122 245
  • 8x2x1 13.9 159 307
  • 10x2x1 16.6 197 393
  • 12x2x1 17.2 233 452
  • 2x2x1.5 10.6 67 146
  • 3x2x1.5 11.4 94 191
  • 4x2x1.5 12.6 122 244
  • 5x2x1.5 14.0 150 296
  • 6x2x1.5 15.4 178 353
  • 8x2x1.5 16.8 232 444
  • 10x2x1.5 20.2 304 582
  • 12x2x1.5 20.9 357 670

Footnote

*Depending on the customer request, the coverage rate can be adjusted.
