LIH(St)CH

SHARE

Product Certificates

You can click to download our certificates.

Areas of Use

These double screened and Halogen Free Flame Retardant cables are used as signal transmission cables in industrial applications. These can be easily used with their flexible construction in narrow applications like electronic control systems of computer or audio systems or the communication sector, electronic circuits, measurement devices, machine design, office equipment, etc. These used for indoor applications. Screening protects the cable from the outer electrical effects. Because of the HFFR material, These don't burn easily and when These do, the flames go off by themselves. These have low smoke density and These don't emit poisonous and corrosive gases during the fire. These used in buildings where there are important goods or human population.

Cable Construction

  • Conductor Stranded Annealed Copper (IEC/EN 60228, Class 5, 0.34 mm²: Class 2)
  • Insulation HFFR (EN 50290-2-26)
  • Core Colors DIN 47100
  • Lay-up Cores are stranded in layers
  • 1. Screen Al-PET Foil
  • 2. Screen Tinned Copper Wire Braid (55% Coverage)
  • Outer Sheath HFFR (EN 50290-2-27), RAL 7001 - Grey
  • Reference Standards VDE 0812, TS 13755

Technical Properties

  • Operating Voltage 0.14 mm²..0.25 mm² 250 V; 0.34 mm²..1.50 mm² 300 V / 500 V
  • Test Voltage 0.14 mm²..25 mm² 1200 V; 0.34 mm²..10 mm² 1500 V; 1.50 mm²….. 2500 V
  • Conductor Resistance 0.14 mm²- ≤138 Ω/km; 0.22 mm²- ≤85 Ω/km; 0.25 mm²- ≤77.8 Ω/km;0.34 mm²- ≤56 Ω/km; 0.50 mm²- ≤39 Ω/km; 0.75 mm²- ≤26 Ω/km; 1.00 mm²- ≤19.5 Ω/km; 1.50 mm²- ≤13.3 Ω/km
  • Insulation Resistance >200 M.Ωxkm
  • Capacitance (@800Hz) Core - Core: 0.14 mm²-≤80 nF/km; 0.22 mm²..0.34 mm²-≤100 nF/km; 0.50 mm²..0.75 mm²-≤110 nF/km; 1.00 mm²..1.50 mm²-≤120nF/km; 2.50 mm²- ≤140 nF/km Core-Screen: 0.14 mm²-≤120 nF/km; 0.22 mm²..0.34 mm²-≤150 nF/km; 0.50 mm²..0.75 mm²-≤170 nF/km; 1.00 mm²..1.50 mm²-≤180nF/km; 2.50 mm²- ≤240 nF/km
  • Indutance (approx.) 0.65 mH/km
  • Temperature Range Fixed: -30 °C ........+70 °C, Flexible: -5 °C ........+70 °C
  • Flame Retardancy IEC/EN 60332-1
  • Smoke Density IEC/EN 61034-2
  • Amount of Halogen Acid Gas IEC/EN 60754-1
  • Corrosive Gases Measurement IEC/EN 60754-2
  • Min. Bending Radius Fixed: 8 x Cable Diameter, Flexible: 15 x Cable Diameter

Cross Section

  • Configuration / Cross-Section (mm/mm²) Cable Diameter (mm) (± 5%) Copper Weight (kg / km) ~ Cable Weight (kg / km)
  • 2x0.22 3.8 9 22
  • 3x0.22 4.0 11 26
  • 4x0.22 4.3 14 31
  • 5x0.22 4.7 17 40
  • 6x0.22 5.1 19 45
  • 7x0.22 5.1 21 47
  • 8x0.22 5.6 24 56
  • 9x0.22 6.0 27 63
  • 10x0.22 6.5 30 68
  • 12x0.22 6.8 34 78
  • 14x0.22 7.1 39 88
  • 16x0.22 7.5 44 100
  • 18x0.22 7.9 49 108
  • 20x0.22 8.4 53 120
  • 25x0.22 9.3 65 146
  • 2x0.34 4.2 12 27
  • 3x0.34 4.3 15 32
  • 4x0.34 4.8 19 40
  • 5x0.34 5.2 23 51
  • 6x0.34 5.7 27 58
  • 7x0.34 5.7 31 61
  • 8x0.34 6.2 34 72
  • 9x0.34 6.7 39 82
  • 10x0.34 7.2 43 87
  • 2x0.5 5.0 15 37
  • 3x0.5 5.3 20 45
  • 4x0.5 5.7 25 55
  • 5x0.5 6.3 30 70
  • 6x0.5 6.9 35 82
  • 7x0.5 6.9 40 85
  • 8x0.5 7.5 45 102
  • 9x0.5 8.1 50 115
  • 10x0.5 8.9 56 125
  • 2x0.75 5.6 20 46
  • 3x0.75 5.8 27 56
  • 4x0.75 6.4 35 71
  • 5x0.75 7.0 42 91
  • 6x0.75 7.7 50 106
  • 7x0.75 7.7 56 111
  • 8x0.75 8.4 64 132
  • 9x0.75 9.1 71 149
  • 10x0.75 10.0 79 162
  • 2x1 5.8 25 53
  • 3x1 6.2 34 67
  • 4x1 6.8 44 84
  • 5x1 7.5 54 108
  • 6x1 8.2 63 127
  • 7x1 8.2 72 133
  • 8x1 9.0 82 158
  • 9x1 9.7 91 178
  • 10x1 10.6 102 194
  • 2x1.5 7.0 35 75
  • 3x1.5 7.4 49 96
  • 4x1.5 8.1 63 121
  • 5x1.5 9.0 77 155
  • 6x1.5 9.8 91 182
  • 7x1.5 9.8 104 192
  • 8x1.5 10.7 119 228
  • 9x1.5 11.6 133 256
  • 10x1.5 12.8 148 282

Footnote

*Depending on the customer request, the coverage rate can be adjusted.
